HTA1SF02T3D15,HTA1DF02T1E20,HTA1WH02T1H35,HTA1DF02T4F40,二位二通电磁阀
二位二通常闭型电磁阀,断电关闭,通电打开阀体材质为SS304不锈钢(常规);
SS316不锈钢(定制)
最大耐压力为:40kgf/cm2
环境温度:0℃～65℃(F级)、0℃～80℃(H级)
产品为系列化生产,体积小,流量大,适用范围广
按阀上所标流向箭头,可任意安装;为增强使用寿命,最好线圈向上,水平安装
电压:AC220V/230V/240V/110V/24V 50/60HZ DC24V/12V +10%到-10%允许波动
线圈可配德国原装NASS线圈 常规备货:AC220V/230V/240V 50/60HZ DC24V
密封件采用聚四氟乙烯材料(Teflon),以适用不同流体的开关控制
|
接管
口径
|
流量
通径
mm
|
CV值 |
线圈
配置
|
功率
|
线圈
等级
|
外形尺寸
长X宽X高
A x B x H
|
重量
KG
|
订货型号以下
表中电压为
220CAC 50/60HZ
|
|
VA
|
W
|
|
AC220V
|
DC24V
|
| 3/8'' |
8 |
4.5 |
|
|
|
|
|
|
HTA1SF02T3D15 |
| 15 |
4.5 |
D |
33 |
32 |
F |
75x52x129 |
1.25 |
HTA1DF02T1C15 |
| 15 |
4.5 |
W |
30 |
25 |
H |
75x52x129 |
1.25 |
HTA1WH02T1C15 |
| 1/2'' |
15 |
4.5 |
D |
33 |
32 |
F |
75x52x129 |
1.2 |
HTA1DF02T1D15 |
| 15 |
4.5 |
W |
30 |
25 |
H |
75x52x129 |
1.2 |
HTA1WH02T1D15 |
| 3/4'' |
20 |
9.0 |
D |
33 |
32 |
F |
85x60x141 |
1.5 |
HTA1DF02T1E20 |
| 20 |
9.0 |
W |
30 |
25 |
H |
85x60x141 |
1.5 |
HTA1WH02T1E20 |
| 1'' |
25 |
13 |
D |
33 |
32 |
F |
100x70x148 |
1.9 |
HTA1DF02T1G25 |
| 25 |
13 |
W |
30 |
25 |
H |
100x70x148 |
1.9 |
HTA1WH02T1G25 |
| 11/4'' |
35 |
26 |
D |
33 |
32 |
F |
120x90x168 |
3.6 |
HTA1DF02T1H35 |
| 35 |
26 |
W |
30 |
25 |
H |
120x90x168 |
3.6 |
HTA1WH02T1H35 |
| 1/2'' |
35 |
26 |
D |
33 |
32 |
F |
120x90x168 |
3.5 |
HTA1DF02T1J35 |
| 35 |
26 |
W |
30 |
25 |
H |
120x90x168 |
3.5 |
HTA1WH02T1J35 |
|
1''
法兰连接
|
25 |
13 |
D |
33 |
32 |
F |
134x110x185 |
3.4 |
HTA1DF02T4F25 |
| 25 |
13 |
W |
30 |
25 |
H |
134x110x185 |
3.4 |
HTA1WH02T4F25 |
11/4''
法兰连接 |
35 |
26 |
D |
33 |
32 |
F |
160x135x200 |
6 |
HTA1DF02T4F35 |
| 35 |
26 |
W |
30 |
25 |
H |
160x135x200 |
6 |
HTA1WH02T4F35 |
1 1/2''
法兰连接 |
40 |
26 |
D |
33 |
32 |
F |
160x145x205 |
6.5 |
HTA1DF02T4F40 |
| 40- |
26 |
W |
30 |
25 |
H |
160x145x205 |
6.5 |
HTA1WH02T4F40 |
