气动接头
首页 > 了解产品 > 气动辅助元件 > 接头类 > 气动接头
S1FB-04WD,S1FB-06WD,S1FB-08WD,S1FB-12WD,S1FB-20WD,S1FB-24WD,S1FB-04-02WD,美制接头
2015-12-10 19:13381
信息概况
  • 价格：未填
  • 型号： S1FB-04WD,S1FB-06WD,S1FB-08WD,S1FB-12WD,S1FB-20WD,S1FB-24WD,S1FB-04-02WD
  • 发货：3天内
发送询价
 S1FB-04WD,S1FB-06WD,S1FB-08WD,S1FB-12WD,S1FB-20WD,S1FB-24WD,S1FB-04-02WD,美制接头

产品技术参数：

代号                              PART  NO. 螺纹  THREAD 尺寸 DIMENSIONS 重量（g) 工作压力MPa
T1 T2 L1 L2 L S1
S1FB-04-02WD 9/16＂X18 M12X1.5 10 11 28.5 17 30 63
S1FB-04WD 9/16＂X18 M14X1.5 10 11 29.5 19 40
S1FB-06-02WD 11/16＂X16 M12X1.5 11 11 32 19 45
S1FB-06-04WD 11/16＂X16 M14X1.5 11 11 32 19 48
S1FB-06WD 11/16＂X16 M16X1.5 11 11.5 33.5 22 60
S1FB-06-08WD 11/16＂X16 M18X1.5 11 12.5 36 24 78
S1FB-08-04WD 13/16＂X16 M14X1.5 13 11 35 22 65
S1FB-08-06WD 13/16＂X16 M16X1.5 13 11.5 36.5 24 76
S1FB-08WD 13/16＂X16 M18X1.5 13 12.5 37 24 80
S1FB-08-12WD 13/16＂X16 M22X1.5 13 13 39.5 27 106
S1FB-08-06WD 13/16＂X16 M27X2 13 16 44 32 160 40
S1FB-10-08WD 1＂X14 M18X1.5 15.5 12.5 41 27 115
S1FB-10-12WD 1＂X14 M22X1.5 15.5 13 42 27 123
S1FB-10-16WD 1＂X14 M27X2 15.5 16.5 47 32 178
S1FB-12-08WD 1.3/16＂X12 M22X1.5 17 13 45 32 175
S1FB-12WD 1.3/16＂X12 M27X2 17 16 48.5 32 198
S1FB-12-16WD 1.3/16＂X12 M33X2 17 16 51.5 41 309
S1FB-16-12WD 1.7/16＂X12 M33X2 17.5 16 52 41 300
S1FB-20WD 1.11/16＂X12 M42X2 17.5 16 54.5 50 451 25
S1FB-24WD 2＂X12 M48X2 17.5 17.5 57 55 557

S1FB-06-02WD,S1FB-06-04WD,S1FB-06-08WD,S1FB-08-04WD,S1FB-08-06WD,S1FB-08-12WD,
S1FB-08-06WD,S1FB-10-08WD,S1FB-10-12WD,S1FB-10-16WD,S1FB-12-08WD,S1FB-12-16WD,
S1FB-16-12WD,
