YD-1000SP1E101A0,YD-1000SP2E102A1,YD-1000SP3E101A5,setech显示器
产品介绍：
|
规 格
|
|
温度补偿范围 －/10℃～85℃
|
显示数 5 位数
|
|
使用温度范围 0℃～60℃
|
精度 ±0.02%
|
|
Reley输出 高，低设定点50v 1A
|
两级显示器 是
|
|
传感器电压 3，4，5 10V DC
|
小数点选择 按钮设置
|
|
接受的输入类型 0.5～3.5 mV/V
|
显示窗尺寸 14mm＆10mm
|
|
传感器电流 120mA
|
最大分辨率 99999
|
|
校正方法 前面板开关
|
类型 7段 LED
|
|
应答主波数 20khz
|
输入/输出连接 按钮
|
|
完全输出 0～5V，10V
|
重量 1000g
|
|
过滤 10Hz，100Hz，1kHz
|
固定 仪表盘安装
|
|
温度变化 0.02% FS/℃
|
尺寸 96mm×96mm
|
|
变换速度 1000 时间/秒
|
电源要求 220V:50/60Hz
（选项110V AC ，24V D C）
|
YD-1000SP2E101A0,YD-1000SP3E101A0,YD-1000SP1E201A0,YD-1000SP2E201A0,YD-1000SP3E201A0,
YD-1000SP1E301A0,YD-1000SP2E301A0,YD-1000SP3E301A0,
YD-1000SP1E102A0,YD-1000SP2E102A0,YD-1000SP3E102A0,YD-1000SP1E202A0,YD-1000SP2E202A0,YD-1000SP3E202A0,
YD-1000SP1E302A0,YD-1000SP2E302A0,setech,YD-1000SP3E302A0,
YD-1000SP1E101A1,YD-1000SP2E101A1,YD-1000SP3E101A1,YD-1000SP1E201A1,YD-1000SP2E201A1,YD-1000SP3E201A1,
YD-1000SP1E301A1,YD-1000SP2E301A1,YD-1000SP3E301A1,
YD-1000SP1E102A1,YD-1000SP3E102A1,YD-1000SP1E202A1,YD-1000SP2E202A1,YD-1000SP3E202A1,
YD-1000SP1E302A1,YD-1000SP2E302A1,YD-1000SP3E302A1,
YD-1000SP1E101A2,YD-1000SP2E101A2,YD-1000SP3E101A2,YD-1000SP1E201A2,YD-1000SP2E201A2,YD-1000SP3E201A2,
YD-1000SP1E301A2,YD-1000SP2E301A2,setech,YD-1000SP3E301A2,
YD-1000SP1E102A2,YD-1000SP2E102A2,YD-1000SP3E102A2,YD-1000SP1E202A2,YD-1000SP2E202A2,YD-1000SP3E202A2,
YD-1000SP1E302A2,YD-1000SP2E302A2,YD-1000SP3E302A2,
YD-1000SP1E101A3,YD-1000SP2E101A3,YD-1000SP3E101A3,YD-1000SP1E201A3,YD-1000SP2E201A3,YD-1000SP3E201A3,
YD-1000SP1E301A3,YD-1000SP2E301A3,YD-1000SP3E301A3,
YD-1000SP1E102A3,YD-1000SP2E102A3,YD-1000SP3E102A3,YD-1000SP1E202A3,YD-1000SP2E202A3,YD-1000SP3E202A3,
YD-1000SP1E302A3,YD-1000SP2E302A3,YD-1000SP3E302A3,
YD-1000SP1E101A5,YD-1000SP2E101A5,YD-1000SP1E201A5,YD-1000SP2E201A5,YD-1000SP3E201A5,
YD-1000SP1E301A5,YD-1000SP2E301A5,YD-1000SP3E301A5,
YD-1000SP1E102A5,YD-1000SP2E102A5,YD-1000SP3E102A5,YD-1000SP1E202A5,YD-1000SP2E202A5,YD-1000SP3E202A5,
YD-1000SP1E302A5,YD-1000SP2E302A5,YD-1000SP3E302A5,
