RTF-M12,RTF-M20,RTF-M30,RTF-M40,RTF-M50,RTF-M60,RTF-PG7,RTF-PG9,RTF-G1/2,弯角快速接头
RTF-M12-10.0,RTF-M16-10.0,RTF-M16-13.0,RTF-M18-13.0,RTF-M20-13.0,RTF-M16-15.8,RTF-M18-15.8,
RTF-M20-15.8,RTF-M20-18.5,RTF-M20-21.2,RTF-M24-21.2,RTF-M25-21.2,RTF-M25-25.0,RTF-M25-28.5,
RTF-M27-28.5,RTF-M30-28.5,RTF-M32-34.5,RTF-M36-34.5,RTF-M40-34.5,RTF-M40-42.5,RTF-M48-42.5,
RTF-M50-54.5,RTF-M60-54.5,RTF-PG7-10.0,RTF-PG9-13.0,RTF-PG11-15.8,RTF-PG13.5-18.5,RTF-PG16-21.2,
RTF-PG21-28.5,RTF-PG29-34.5,RTF-PG36-42.5,RTF-PG48-54.5,RTF-G1/2-21.2,RTF-G1/2-25.0,
RTF-G3/4-28.5,RTF-G1-34.5,
| 适配软管 |
编号 |
螺牙规格 |
螺纹外径 |
螺纹内径(mm) |
螺纹长度(mm) |
E(mm) |
F(mm) |
| AD10.0 |
RTF-M12-10.0 |
M12 x 1.5 |
12 |
9 |
10 |
32 |
16 |
| AD11.6 |
RTF-M16-10.0 |
M16 x 1.5 |
16 |
11 |
10 |
34.5 |
20 |
| AD13.0 |
RTF-M16-13.0 |
M16 x 1.5 |
16 |
11.6 |
10 |
34.5 |
20 |
| RTF-M18-13.0 |
M18 x 1.5 |
18 |
10 |
10 |
37.5 |
24.3 |
| RTF-M20-13.0 |
M20 x 1.5 |
20 |
13 |
10 |
37.5 |
24.3 |
| AD15.8 |
RTF-M16-15.8 |
M16 x 1.5 |
16 |
12 |
10 |
37.5 |
24.3 |
| RTF-M18-15.8 |
M18 x 1.5 |
18 |
12 |
10 |
37.5 |
24.3 |
| RTF-M20-15.8 |
M20 x 1.5 |
20 |
15 |
10 |
37.5 |
24.3 |
| AD18.5 |
RTF-M20-18.5 |
M20 x 1.5 |
20 |
16 |
11.5 |
43.5 |
27 |
| AD21.2 |
RTF-M20-21.2 |
M20 x 1.5 |
20 |
15 |
13 |
49 |
31 |
| RTF-M24-21.2 |
M24 x 1.5 |
24 |
17 |
13 |
49 |
31 |
| RTF-M25-21.2 |
M25 x 1.5 |
25 |
16 |
13 |
49 |
31 |
| AD25.0 |
RTF-M25-25.0 |
M25 x 1.5 |
25 |
19.5 |
13 |
52 |
32 |
| AD28.5 |
RTF-M25-28.5 |
M25 x 1.5 |
25 |
19.5 |
13 |
57 |
34 |
| RTF-M27-28.5 |
M27 x 2.0 |
27 |
23 |
13 |
57 |
34 |
| RTF-M30-28.5 |
M30 x 2.0 |
30 |
23 |
13 |
57 |
34 |
| AD34.5 |
RTF-M32-34.5 |
M32 x 1.5 |
32 |
27 |
14.5 |
64 |
43 |
| RTF-M36-34.5 |
M36 x 2.0 |
36 |
29 |
14.5 |
64 |
43 |
| RTF-M40-34.5 |
M40 x 1.5 |
40 |
30 |
14.5 |
64 |
43 |
| AD42.5 |
RTF-M40-42.5 |
M40 x 1.5 |
40 |
35 |
14.5 |
72 |
50 |
| RTF-M48-42.5 |
M48 x 2.0 |
48 |
38 |
14.5 |
72 |
50 |
| AD54.5 |
RTF-M50-54.5 |
M50 x 1.5 |
50 |
44 |
16 |
84 |
64 |
| RTF-M60-54.5 |
M60 x 2.0 |
60 |
53 |
16 |
84 |
64 |
| AD10.0 |
RTF-PG7-10.0 |
PG7 |
12.5 |
9 |
10 |
32 |
16 |
| AD13.0 |
RTF-PG9-13.0 |
PG9 |
15.2 |
11.6 |
10 |
34.5 |
20 |
| AD15.8 |
RTF-PG11-15.8 |
PG11 |
18.6 |
13.5 |
10 |
37.5 |
24.3 |
| AD18.5 |
RTF-PG13.5-18.5 |
PG13.5 |
20.4 |
16 |
11 |
43.5 |
27 |
| AD21.2 |
RTF-PG16-21.2 |
PG16 |
22.5 |
17.5 |
13 |
49 |
31 |
| AD28.5 |
RTF-PG21-28.5 |
PG21 |
28.3 |
23 |
13 |
57 |
34 |
| AD34.5 |
RTF-PG29-34.5 |
PG29 |
37 |
30 |
14.5 |
64 |
43 |
| AD42.5 |
RTF-PG36-42.5 |
PG36 |
47 |
38 |
14.5 |
72 |
50 |
| AD54.5 |
RTF-PG48-54.5 |
PG48 |
59.3 |
52 |
16 |
84 |
64 |
| AD21.2 |
RTF-G1/2-21.2 |
G1/2 |
22.5 |
15 |
13 |
49 |
31 |
| AD25.0 |
RTF-G1/2-25.0 |
G1/2 |
25 |
15 |
13 |
52 |
32 |
| AD28.5 |
RTF-G3/4-28.5 |
G3/4 |
28.3 |
21 |
13 |
57 |
34 |
| AD34.5 |
RTF-G1-34.5 |
G1 |
37 |
32 |
14.5 |
64 |
43 |
