产品特点

系列中流量不锈钢减压器，单级式膜片减压结构，不锈钢膜片压力传输，输出压力稳定，主要应用于大流量气体系统，适用于纯净气体、标准气体、腐蚀性气体等。

■ 设计特点

● 单级式减压结构　　● 母体与膜片采用硬密封形式　　● 母体螺纹：进出气接口3/4" NPT（F），压力表，安全阀接口1/4〞NPT（F）　　● 内部结构易吹扫　　　● 内设过滤网　　　　 ● 可采用面板或墙式安装

■ 适用范围

● 气体吹扫系统　　● 特种气体　　● 气体汇流排　　● 石油化学工业

■ 特性参数

● 最大输入压力： 500，3000psig　　　　　　 ● 输出压力：0~15,0~25,0~70,0~125psig
● 安全测试压力：1.5倍的最大进气压力　　　　● 适用温度：-40℉~+165℉(-40℃~+74℃) 　　　● 泄漏率：2x10-8 atm cc/sec He
● CV值：1.8　　　● 重量：2.7kg

■ 材质

系列	R13L	R13B	R13S
母体	SS316L	Brass nickel plated	SS316L
上盖	300 Series stainless steel	Brass nickel plated	300 Series stainless steel
垫片	PCTFE	PCTFE	PCTFE
阀杆	SS316L	SS316L	SS316L
膜片	SS316L	SS316L	SS316L

订购指南

EX:R13	L	B	E	H	G	0 4	0 4	P
系列号	母体材质	母体孔位	输入压力	输出压力	压力表	进气形式	出气形式	选项
R13	L：SS316L	A	E:1500 psig	H：0-125psig	G:附压力表	04：1/2" NPT(F)	04：1/2" NPT(F)	P:面板式安装
	B：Brass	B	F:500 psig	J： 0-75psig	（MPa）	05：1/2" NPT(M)	05：1/2" NPT(M)	R：安全阀
	S：SS304	D		L：0-25psig	P:附压力表	06：3/4" NPT(F)	06：3/4" NPT(F)
		G		M：0~15psig	(psig/bar)	13：1/2"卡套接頭	13：1/2"卡套接頭
		J		Q：30〃Hg Vac-30psig	W:无压力表	14：3/4"卡套接頭	14：3/4"卡套接頭
		M		S：30〃Hg Vac-60psig		其它形式接头可供选择	其它形式接头可供选择
				T：30〃Hg Vac-100psig

R13LAEHG,R13LBEHG,R13LDEHG,R13LGEHG,R13LJEHG,R13LMEHG,
R13LAFHG,R13LBFHG,R13LDFHG,R13LGFHG,R13LJFHG,R13LMFHG,
R13LAEJG,R13LBEJG,R13LDEJG,R13LGEJG,R13LJEJG,R13LMEJG,
R13LAFJG,R13LBFJG,R13LDFJG,R13LGFJG,R13LJFJG,R13LMFJG,
R13LAELG,R13LBELG,R13LDELG,R13LGELG,R13LJELG,R13LMELG,
R13LAFLG,R13LBFLG,R13LDFLG,R13LGFLG,R13LJFLG,R13LMFLG,
R13LAEMG,CCLAIR,R13LDEMG,R13LGEMG,R13LJEMG,R13LMEMG,
R13LAFMG,R13LBFMG,R13LDFMG,R13LGFMG,R13LJFMG,R13LMFMG,
R13LAEQG,R13LBEQG,R13LDEQG,R13LGEQG,R13LJEQG,R13LMEQG,
R13LAFQG,R13LBFQG,R13LDFQG,R13LGFQG,R13LJFQG,R13LMFQG,
R13LAESG,R13LBESG,R13LDESG,R13LGESG,R13LJESG,R13LMESG,
R13LAFSG,R13LBFSG,R13LDFSG,R13LGFSG,R13LJFSG,R13LMFSG,
R13LAETG,R13LBETG,R13LDETG,R13LGETG,R13LJETG,R13LMETG,
R13LAFTG,R13LBFTG,R13LDFTG,R13LGFTG,R13LJFTG,R13LMFTG,
R13LAEHP,R13LBEHP,R13LDEHP,R13LGEHP,R13LJEHP,R13LMEHP,
R13LAFHP,R13LBFHP,R13LDFHP,R13LGFHP,R13LJFHP,R13LMFHP,
R13LAEJP,R13LBEJP,R13LDEJP,R13LGEJP,R13LJEJP,R13LMEJP,
R13LAFJP,R13LBFJP,R13LDFJP,R13LGFJP,R13LJFJP,R13LMFJP,
R13LAELP,R13LBELP,R13LDELP,R13LGELP,R13LJELP,R13LMELP,
R13LAFLP,R13LBFLP,R13LDFLP,R13LGFLP,R13LJFLP,R13LMFLP,
R13LAEMP,R13LBEMP,R13LDEMP,R13LGEMP,R13LJEMP,R13LMEMP,
R13LAFMP,R13LBFMP,R13LDFMP,R13LGFMP,R13LJFMP,R13LMFMP,
R13LAEQP,R13LBEQP,R13LDEQP,R13LGEQP,R13LJEQP,R13LMEQP,
R13LAFQP,R13LBFQP,R13LDFQP,R13LGFQP,R13LJFQP,R13LMFQP,
R13LAESP,R13LBESP,CCLAIR,R13LGESP,R13LJESP,R13LMESP,
R13LAFSP,R13LBFSP,R13LDFSP,R13LGFSP,R13LJFSP,R13LMFSP,
R13LAETP,R13LBETP,R13LDETP,R13LGETP,R13LJETP,R13LMETP,
R13LAFTP,R13LBFTP,R13LDFTP,R13LGFTP,R13LJFTP,R13LMFTP,
R13LAEHW,R13LBEHW,R13LDEHW,R13LGEHW,R13LJEHW,R13LMEHW,
R13LAFHW,R13LBFHW,R13LDFHW,R13LGFHW,R13LJFHW,R13LMFHW,
R13LAEJW,R13LBEJW,R13LDEJW,R13LGEJW,R13LJEJW,R13LMEJW,
R13LAFJW,R13LBFJW,R13LDFJW,R13LGFJW,R13LJFJW,R13LMFJW,
R13LAELW,R13LBELW,R13LDELW,R13LGELW,R13LJELW,R13LMELW,
R13LAFLW,R13LBFLW,R13LDFLW,R13LGFLW,R13LJFLW,R13LMFLW,
R13LAEMW,R13LBEMW,R13LDEMW,R13LGEMW,R13LJEMW,R13LMEMW,
R13LAFMW,R13LBFMW,R13LDFMW,R13LGFMW,R13LJFMW,R13LMFMW,
R13LAEQW,R13LBEQW,R13LDEQW,R13LGEQW,R13LJEQW,R13LMEQW,
R13LAFQW,R13LBFQW,R13LDFQW,R13LGFQW,R13LJFQW,R13LMFQW,
R13LAESW,R13LBESW,R13LDESW,R13LGESW,R13LJESW,R13LMESW,
R13LAFSW,R13LBFSW,R13LDFSW,R13LGFSW,R13LJFSW,R13LMFSW,
R13LAETW,R13LBETW,R13LDETW,R13LGETW,R13LJETW,R13LMETW,
R13LAFTW,R13LBFTW,R13LDFTW,R13LGFTW,R13LJFTW,R13LMFTW,
R13BAEHG,R13BBEHG,CCLAIR,R13BDEHG,R13BJEHG,R13BMEHG,
R13BAFHG,R13BBFHG,R13BDFHG,R13BGFHG,R13BJFHG,R13BMFHG,
R13BAEJG,R13BBEJG,R13BDEJG,R13BGEJG,R13BJEJG,R13BMEJG,
R13BAFJG,R13BBFJG,R13BDFJG,R13BGFJG,R13BJFJG,R13BMFJG,
R13BAELG,R13BBELG,R13BDELG,R13BGELG,R13BJELG,R13BMELG,
R13BAFLG,R13BBFLG,R13BDFLG,R13BGFLG,R13BJFLG,R13BMFLG,
R13BAEMG,R13BBEMG,R13BDEMG,R13BGEMG,R13BJEMG,R13BMEMG,
R13BAFMG,R13BBFMG,R13BDFMG,R13BGFMG,R13BJFMG,R13BMFMG,
R13BAEQG,R13BBEQG,R13BDEQG,R13BGEQG,R13BJEQG,R13BMEQG,
R13BAFQG,R13BBFQG,R13BDFQG,R13BGFQG,R13BJFQG,R13BMFQG,
R13BAESG,R13BBESG,R13BDESG,R13BGESG,R13BJESG,R13BMESG,
R13BAFSG,R13BBFSG,R13BDFSG,R13BGFSG,R13BJFSG,R13BMFSG,
R13BAETG,R13BBETG,R13BDETG,R13BGETG,R13BJETG,R13BMETG,
R13BAFTG,R13BBFTG,R13BDFTG,R13BGFTG,R13BJFTG,R13BMFTG,
R13BAEHP,R13BBEHP,R13BDEHP,R13BGEHP,R13BJEHP,R13BMEHP,
R13BAFHP,R13BBFHP,R13BDFHP,R13BGFHP,R13BJFHP,R13BMFHP,
R13BAEJP,R13BBEJP,R13BDEJP,R13BGEJP,R13BJEJP,R13BMEJP,
R13BAFJP,R13BBFJP,R13BDFJP,R13BGFJP,R13BJFJP,R13BMFJP,
R13BAELP,R13BBELP,CCLAIR,R13BDELP,R13BGELP,R13BMELP,
R13BAFLP,R13BBFLP,R13BDFLP,R13BGFLP,R13BJFLP,R13BMFLP,
R13BAEMP,R13BBEMP,R13BDEMP,R13BGEMP,R13BJEMP,R13BMEMP,
R13BAFMP,R13BBFMP,R13BDFMP,R13BGFMP,R13BJFMP,R13BMFMP,
R13BAEQP,R13BBEQP,R13BDEQP,R13BGEQP,R13BJEQP,R13BMEQP,
R13BAFQP,R13BBFQP,R13BDFQP,R13BGFQP,R13BJFQP,R13BMFQP,
R13BAESP,R13BBESP,R13BDESP,R13BGESP,R13BJESP,R13BMESP,
R13BAFSP,R13BBFSP,R13BDFSP,R13BGFSP,R13BJFSP,R13BMFSP,
R13BAETP,R13BBETP,R13BDETP,R13BGETP,R13BJETP,R13BMETP,
R13BAFTP,R13BBFTP,R13BDFTP,R13BGFTP,R13BJFTP,R13BMFTP,
R13BAEHW,R13BBEHW,R13BDEHW,R13BGEHW,R13BJEHW,R13BMEHW,
R13BAFHW,R13BBFHW,R13BDFHW,R13BGFHW,R13BJFHW,R13BMFHW,
R13BAEJW,R13BBEJW,R13BDEJW,R13BGEJW,R13BJEJW,R13BMEJW,
R13BAFJW,R13BBFJW,R13BDFJW,R13BGFJW,R13BJFJW,R13BMFJW,
R13BAELW,R13BBELW,R13BDELW,R13BGELW,R13BJELW,R13BMELW,
R13BAFLW,R13BBFLW,R13BDFLW,R13BGFLW,R13BJFLW,R13BMFLW,
R13BAEMW,R13BBEMW,R13BDEMW,R13BGEMW,R13BJEMW,R13BMEMW,
R13BAFMW,R13BBFMW,R13BDFMW,R13BGFMW,R13BJFMW,R13BMFMW,
R13BAEQW,R13BBEQW,CCLAIR,R13BDEQW,R13BGEQW,R13BJEQW,
R13BAFQW,R13BBFQW,R13BDFQW,R13BGFQW,R13BJFQW,R13BMFQW,
R13BAESW,R13BBESW,R13BDESW,R13BGESW,R13BJESW,R13BMESW,
R13BAFSW,R13BBFSW,R13BDFSW,R13BGFSW,R13BJFSW,R13BMFSW,
R13BAETW,R13BBETW,R13BDETW,R13BGETW,R13BJETW,R13BMETW,
R13BAFTW,R13BBFTW,R13BDFTW,R13BGFTW,R13BJFTW,R13BMFTW,
R13SAEHG,R13SBEHG,R13SDEHG,R13SGEHG,R13SJEHG,R13SMEHG,
R13SAFHG,R13SBFHG,R13SDFHG,R13SGFHG,R13SJFHG,R13SMFHG,
R13SAEJG,R13SBEJG,R13SDEJG,R13SGEJG,R13SJEJG,R13SMEJG,
R13SAFJG,R13SBFJG,R13SDFJG,R13SGFJG,R13SJFJG,R13SMFJG,
R13SAELG,R13SBELG,R13SDELG,R13SGELG,R13SJELG,R13SMELG,
R13SAFLG,R13SBFLG,R13SDFLG,R13SGFLG,R13SJFLG,R13SMFLG,
R13SAEMG,R13SBEMG,R13SDEMG,R13SGEMG,R13SJEMG,R13SMEMG,
R13SAFMG,R13SBFMG,R13SDFMG,R13SGFMG,R13SJFMG,R13SMFMG,
R13SAEQG,R13SBEQG,R13SDEQG,R13SGEQG,R13SJEQG,R13SMEQG,
R13SAFQG,R13SBFQG,R13SDFQG,R13SGFQG,R13SJFQG,R13SMFQG,
R13SAESG,R13SBESG,R13SDESG,R13SGESG,R13SJESG,R13SMESG,
R13SAFSG,R13SBFSG,R13SDFSG,R13SGFSG,R13SJFSG,R13SMFSG,
R13SBETG,CCLAIR,R13SDETG,R13SGETG,R13SJETG,R13SMETG,
R13SAFTG,R13SBFTG,R13SDFTG,R13SGFTG,R13SJFTG,R13SMFTG,
R13SAEHP,R13SBEHP,R13SDEHP,R13SGEHP,R13SJEHP,R13SMEHP,
R13SAFHP,R13SBFHP,R13SDFHP,R13SGFHP,R13SJFHP,R13SMFHP,
R13SAEJP,R13SBEJP,R13SDEJP,R13SGEJP,R13SJEJP,R13SMEJP,
R13SAFJP,R13SBFJP,R13SDFJP,R13SGFJP,R13SJFJP,R13SMFJP,
R13SAELP,R13SBELP,R13SDELP,R13SGELP,R13SJELP,R13SMELP,
R13SAFLP,R13SBFLP,R13SDFLP,R13SGFLP,R13SJFLP,R13SMFLP,
R13SAEMP,R13SBEMP,R13SDEMP,R13SGEMP,R13SJEMP,R13SMEMP,
R13SAFMP,R13SBFMP,R13SDFMP,R13SGFMP,R13SJFMP,R13SMFMP,
R13SAEQP,R13SBEQP,R13SDEQP,R13SGEQP,R13SJEQP,R13SMEQP,
R13SAFQP,R13SBFQP,R13SDFQP,R13SGFQP,R13SJFQP,R13SMFQP,
R13SAESP,R13SBESP,R13SDESP,R13SGESP,R13SJESP,R13SMESP,
R13SAFSP,R13SBFSP,R13SDFSP,R13SGFSP,R13SJFSP,R13SMFSP,
R13SAETP,R13SBETP,R13SDETP,R13SGETP,R13SJETP,R13SMETP,
R13SAFTP,R13SBFTP,R13SDFTP,R13SGFTP,R13SJFTP,R13SMFTP,
R13SAEHW,R13SBEHW,R13SDEHW,R13SGEHW,R13SJEHW,R13SMEHW,
R13SAFHW,R13SBFHW,R13SDFHW,R13SGFHW,R13SJFHW,R13SMFHW,
R13SAEJW,R13SBEJW,CCLAIR,R13SDEJW,R13SGEJW,R13SJEJW,R13SMEJW,
R13SAFJW,R13SBFJW,R13SDFJW,R13SGFJW,R13SJFJW,R13SMFJW,
R13SAELW,R13SBELW,R13SDELW,R13SGELW,R13SJELW,R13SMELW,
R13SAFLW,R13SBFLW,R13SDFLW,R13SGFLW,R13SJFLW,R13SMFLW,
R13SAEMW,R13SBEMW,R13SDEMW,R13SGEMW,R13SJEMW,R13SMEMW,
R13SAFMW,R13SBFMW,R13SDFMW,R13SGFMW,R13SJFMW,R13SMFMW,
R13SAEQW,R13SBEQW,R13SDEQW,R13SGEQW,R13SJEQW,R13SMEQW,
R13SAFQW,R13SBFQW,R13SDFQW,R13SGFQW,R13SJFQW,R13SMFQW,
R13SAESW,R13SBESW,R13SDESW,R13SGESW,R13SJESW,R13SMESW,
R13SAFSW,R13SBFSW,R13SDFSW,R13SGFSW,R13SJFSW,R13SMFSW,
R13SAETW,R13SBETW,R13SDETW,R13SGETW,R13SJETW,R13SMETW,
R13SAFTW,R13SBFTW,R13SDFTW,R13SGFTW,R13SJFTW,R13SMFTW,
