真空球阀

首页 > 了解产品 > 阀门流体控制 > 真空阀门 > 真空球阀

GIQ-40,GIQ-50,GIQ-63,GIQ-80,GIQ-100,GIQ-125,GIQ-150,GIQ-200,GIQ-250,GIQ-300,GIQ-400,气动高真空蝶阀

2013-06-18 13:331346

信息概况

价格：未填
型号：GIQ-40,GIQ-50,GIQ-63,GIQ-80,GIQ-100,GIQ-125,GIQ-150,GIQ-200,GIQ-250,GIQ-300,GIQ-400,
发货：3天内

GIQ-40,GIQ-50,GIQ-63,GIQ-80,GIQ-100,GIQ-125,GIQ-150,GIQ-200,GIQ-250,GIQ-300,GIQ-400,气动高真空蝶阀,生产厂家,价格
GIQ-500,GIQ-800,GIQ-1000,GIQ-1200,

规格型号	DN	D	Do	D1	B	H	B1	L	n-φc
GIQ-40	40	85	70	44	22	162	90	104	4-φ7
GIQ-50	50	110	90	55	22	175	90	104	4-φ7
GIQ-65	65	125	105	70	26	198	102	140	4-φ9
GIQ-80	80	145	125	85	30	208	102	140	4-φ9
GIQ-100	100	170	145	105	30	220	102	140	4-φ12
GIQ-150	150	220	195	156	35	272	115	164	8-φ12
GIQ-200	200	275	250	208	40	330	205	190	8-φ12
GIQ-250	250	330	300	258	45	335	205	190	8-φ14
GIQ-300	300	380	350	308	55	426	152	247	8-φ14
GIQ-400	400	500	465	410	60	520	180	308	8-φ18
GIQ-500	500	600	565	510	80	643	220	378	12-φ18
GIQ-600	600	710	670	610	100	760	270	524	12-φ21
GIQ-800	800	920	815	815	130	962	320	648	20-φ21
GIQ-1000	1000	1120	1090	1015	140	980	380	1480	32-φ14
GIQ-1200	1200	1440	1280	1280	150	1360	385	1480	36-φ19
